Our PCIe (Peripheral Component Interconnect Express) solutions offer exceptional scalability, reliability, and low-latency connectivity, making them ideal for modern high-performance computing environments. Seamlessly integrating with a wide range of third-party products, including GPUs and SSDs, our systems provide flexible and scalable options for processing and storage. Explore our pre-defined systems below or contact us for custom solutions tailored to your specific needs.


​System Configurations and Comparison​
System Name ADQ35-INT X 2​ DPS7-PCIe​ DPS16-PCIe​
Description​
 2 x ADQ35 Interleaved (20 GSPS) + GPU + PC Industrial PC with 7 PCIe slots + ADQ3x + GPU + PC+ Disks 16 slots per chassi  + ADQ3x + GPU + Disks
PC chassis​
 Rack mounted or tower Rack mounted Rack mounted or tower
​PCIe expansion chassis
 ​N/A
 ​N/A​
 ​Bressner OSS-PCIe3-xxx
Bressner OSS-PCIe4-xxx
​GPU options
 ​Nvidia Pro A400, A2000 or A4000
 ​​Nvidia Pro A400, A2000 or A4000
 ​Nvidia Pro A400, A2000 or A4000
PC motherboard options
 ​ASUS Pro WS WRX80E-SAGE SE WIFI,
Supermicro MBD-H12SSL-I-O​
 ​ASUS Pro WS WRX80E-SAGE SE WIFI
 ​Supermicro MBD-H12SSL-I-O​
​PC CPU options
 ​​AMD Ryzen Threadripper PRO 5955WX 4 GHz 73 MB,
AMD Epyc 7282 - 16 Core, 2.80 GHz, 64 MB
 ​AMD Ryzen Threadripper PRO 5955WX 4 GHz 73 MB


 ​AMD Epyc 7282 - 16 Core, 2.80 GHz, 64 MB
​SSD (disk) mounting options
 ​Motherboard or PCIe expansion card
 ​​Motherboard or PCIe expansion card
 ​​Motherboard or PCIe expansion card
​Number of disks
 ​Multiple
 ​Multiple
 ​Multiple
​Streaming per disk
 ​6 Gbyte/s
 ​6 Gbyte/s
 ​6 Gbyte/s
Target applications Wideband RF recording, pulse detection, mass spectrometry, LiDAR, radar, signals intelligence, automated test equipment, digital oscillioscope.
 General data acquisition, automated test equipment, LiDAR, particle detection. Multi-channel single-shot, Thomson scattering, MIMO, synchrotron.
​

Digitizer Analog Performance​

Sampling rate (GSPS)
 1 channel at 20 or 2 channels at 10​​ 1 to 10 per channel 1 to 10 per channel
Resolution​ (bits)​ 12​ 12
 12
Channel count
 1 or 2 (software-selectable) Up to 14 channels per system
 ​Up to 32 channels per chassis
Bandwidth (GHz)
 2.5, 9.0 1.0, 2.5, 9.0​
 1.0, 2.5, 9.0

​ Data Streaming and Processing

Throughput (Gbyte/s) 28
 14 per slot
 3.5 per slot
Duty cycle, continuous streaming​
 100% with 10-bit compression 100%
 Not applicable
GPU​
 ​Nvidia Pro A400, A2000 or A4000
 Nvidia Pro A400, A2000 or A4000
 ​Nvidia Pro A400, A2000 or A4000​
SSD (disk) performance  Up to 28 Gbyte/s streaming Yes (Linux)
 Yes (Linux)​

​ Software and Firmware​

Operating system
 Linux
 Linux, Windows
 Linux, Windows
LIBADS
 Linux​ Linux, Windows
 Linux, Windows
Software: design framework for GPU​
 Digitizer Studio, C, C++, Python, Cuda
 Digitizer Studio, LabView, Matlab, C, C++, Python, Cuda
 Digitizer Studio, LabView, Matlab, C, C++, Python, Cuda
Firmware
 FWATD All options avaliable
 All options avaliable

​ Hardware Options and Synchronization

19" rack mount option
 Yes Yes
 Yes
Master/Slave
 N/A N/A
 Stack & Rack -> 32 slots​
Timing & synchronization, daisy-chain
 +/- 10 ps +/- 10 ps
 +/- 10 ps​​​​​​​​​​​​​​​​​​​​
